LS-5004M | Lead Gage Setting Standard

Lead standard for metric threads, 1, 1.5, 2, 3, & 4 mm pitches, Connection: Metric Straight, Pitch: 1, 1.5, 2, 3, & 4 mm, TPI: 1, 1.5, 2, 3, & 4 mm, TPF: -, Thread Form: Metric Straight

recision Metric Calibration for Thread Lead Inspection

The Gagemaker LS‑5004M is a certified Metric Lead Gage Setting Standard designed for accurate presetting of Gagemaker lead gages used in metric straight thread inspection. Manufactured to exact tolerances, this standard provides a stable, repeatable reference point for verifying thread lead on metric components — ensuring your machining, QA, and inspection processes remain precise and compliant.

Built for demanding industrial environments, the LS‑5004M helps eliminate lead‑cutting errors, detect worn machine screws, and maintain consistent thread quality across production.

GAGEMAKER LS-5004M: Lead Standard, Metric 1 mm, 1.5 mm, 2 mm, 3 mm, 4 mm, & 6 mm Pitches.
