RG-7002 | External Functional Size Thread Inspection Gauges| Functional Size Gauges

External Thread Roll Gage, Range: 8” - 12” (203.2 mm - 304.8 mm), Resolution: 0.0005" ,Travel: 1/2"

These functional size inspection (or “GO/NO GO”) gages measure external thread diameters ranging from ⅝” – 24″.

The gages are adjustable within a size range and use interchangeable thread rolls to measure different pitch threads.

Setting dimensions for the functional pitch diameter gages are provided by the TDWIN Thread Disk Software.

Indicators have a .5″ travel and .0005″ resolution with higher resolutions available.

GAGEMAKER RG-7002: Thread Roll Gage, External,
8" - 12" Range
