TP-3-1.25-84 | Rotary Shouldered Connection Form Profiles | Tapered Thread Form Profile Gages | Thread Form Profiles

The Gagemaker TP‑3‑1.25‑84 is a precision tapered thread form profile gage engineered for fast, accurate inspection of rotary shouldered connections. It provides a quick visual check of thread form quality, helping machinists and inspectors detect wear, damage, or machining errors before the connection is put into service.

Key Features

• Designed for Rotary Shouldered Connections Ideal for verifying thread form integrity on premium and API‑style connections.

• Accurate Thread Form Verification Identifies common thread issues such as: chipped inserts, lead error, burrs, debris, flat crests, stretched threads, rolled‑over threads, and other form deviations.

• Precision Tapered Profile Specs

  • TPI: 3

  • TPF: 1.25"

  • Thread Form: V‑0.084

• Fast Visual Inspection Insert the profile into the threads and shine a light behind it to instantly reveal imperfections.

• Industrial‑Grade Durability Manufactured by Gagemaker for long‑term accuracy and dependable performance in both shop and field environments.

GAGEMAKER TP-3-1.25-84: Thread Profile
3 Threads per Inch, 1.250 TPF, Slimline H-90, 90-V-084 2-3/8" - 3-1/2" Hughes Slim Line H-90
