TP-6-2-32 | Rotary Shouldered Connection Form Profiles |Tapered Thread Form Profile Gages |Thread Form Profiles

Connection Type: Hughes External Flush, Connection Size: 2⅜” - 2⅞”, TPI: 6, TPF: 2", Thread Form: V-0.032

The Gagemaker TP‑6‑2‑32 is a precision‑engineered tapered thread form profile gage designed for fast, reliable inspection of Hughes External Flush connections. Built for demanding industrial environments, this profile gage helps manufacturers and inspectors verify thread form accuracy, detect wear or damage, and ensure proper connection make‑up.

Industrial‑Grade Construction Manufactured by Gagemaker for long service life, consistent accuracy, and dependable performance in both shop and field environments. Simply place the profile into the threads and shine a light behind it to instantly detect form deviations.

GAGEMAKER TP-6-2-32: Thread Profile
6 Threads per Inch, 2.000 TPF, V-032 2-3/8" - 2-7/8" Hughes External Flush
