TP-745-__P | Straight Thread Form Profile Gages | Thread Form Profiles

External/Internal 7° x 45° Buttress thread form profile gage, Thread Form: 7 X 45 Buttress, Type: External/Internal

TP‑745‑__P | 7° × 45° Buttress Thread Form Profile Gage

The Gagemaker TP‑745‑__P Series provides fast, accurate inspection of 7° × 45° Buttress straight threads, ensuring proper form, pitch, and thread geometry. These precision‑cut profile gages offer immediate visual verification, helping manufacturers detect machining defects early, reduce scrap, and maintain consistent thread quality.

Key Features

• Designed for 7° × 45° Buttress Threads Confirms correct form, pitch, and profile for both internal and external Buttress straight threads.

• Instant Visual Verification Light‑based inspection quickly reveals machining defects or wear.

• Precision Manufacturing Gagemaker’s high‑accuracy profiles ensure consistent, repeatable results.

• Durable Shop‑Floor Construction Built for daily use in demanding industrial environments.

• Fast, Simple, and Cost‑Effective No setup required—insert, illuminate, inspect.

GAGEMAKER TP-745-__P SERIES: Thread Profile 7° x 45° Buttress, Threads depending on the item.

INCLUDES: TP-745-2P, TP-745-3P, TP-745-4P, TP-745-5P, TP-745-6P, TP-745-8P, TP-745-10P, TP-745-12P, TP-745-16P, TP-745-3.5P
