TP-ME-__P | Straight Thread Form Profile Gages | Thread Form Profiles

External ISO Metric series thread form profile gage

Thread Form: ISO Metric, Type: External

The Gagemaker TP‑ME‑__P Series delivers fast, reliable inspection of ISO Metric external straight threads, ensuring your threaded components meet proper form, pitch, and profile standards. Built with precision and engineered for daily shop‑floor use, these profile gages provide an immediate visual check of thread quality—helping you detect defects before they become costly production issues.

Key Features

• Precision ISO Metric External Thread Verification Confirms correct form, pitch, and profile for ISO Metric series external threads.

• Instant Visual Inspection Light‑based method quickly reveals defects, wear, or machining errors.

• High‑Accuracy Manufacturing Gagemaker’s precision‑cut profiles ensure consistent, repeatable results.

• Durable Shop‑Floor Construction Built to withstand daily use in machining and inspection environments.

• Simple, Fast, and Cost‑Effective No setup required—just insert, illuminate, and inspect.

Replace __P with the pitch you need:

 TP‑ME‑1P

TP‑ME‑2P

TP‑ME‑3P

TP-ME-4P

TP-ME-6P

TP-ME-8P

TP-ME-1.5

TP-ME-2.5

TP-ME-3.5
