TP-NPT-14 | Other Form Profiles | Thread Form Profiles

The Gagemaker TP‑NPT‑14 is a precision tapered thread form profile gauge designed for quick, reliable inspection of 14 TPI NPT pipe threads. Ideal for machining, fabrication, and industrial maintenance, this gauge provides a fast visual method to verify proper thread form, detect wear, and ensure compliance with NPT standards.

Key Features

• Designed for 14 TPI NPT Threads Built specifically for ¾″ NPT tapered thread forms used across piping, fittings, and industrial components.

• External & Internal Thread Inspection Suitable for checking both male and female NPT threads for correct form, pitch, taper, and alignment.

• Fast Visual Verification Insert the profile into the thread and shine a light behind it to instantly identify lead errors, chipped inserts, burrs, debris, or worn thread geometry.

• Detects Common Thread Defects Helps identify flat crests, stretched threads, rolled‑over threads, wide first threads, and other machining issues.

• Durable Industrial Construction Manufactured for long‑term use in machine shops, QC labs, and field service environments.

GAGEMAKER TP-NPT-14: Thread Profile, NPT
14 Threads per Inch, 0.750 TPF
